Invicta

Never look back.
The 2021 Holiday Rambler Invicta has everything you need to keep moving, no matter where your wanderlust leads. Standard traction control and four-point fully automatic hydraulic leveling jacks help you conquer every hill and hug every curve. An all-new electronic instrument panel lets you hit the road with confidence. And loads of onboard innovations like the lighted power entry step, Illumaplex MultiPlex control system, and Sony® Dash Stereo with CarPlay keep the whole crew comfortable. On top of it all, bold new fabrics and finishes and two new floorplan options let you make it your own. Whether it’s your first RV or a long-awaited upgrade, the Invicta puts dream vacations in reach.
-
Chassis
Chassis Type:
Ford F-53 Motorhome Chassis
GVWR:
22000
GCWR:
26000
Rear Axle GAWR:
15000
Front Axle GAWR:
8000
Hitch Rating:
8000
Tongue Rating:
800
Front suspension: Tapered Multi-Leaf:
S
Rear suspension: Tapered Multi-Leaf:
S
Power - 4 Wheel Disc (Hydro-boost) w/ABS:
S
Shock Absorbers - Bilstein™ 1.63-in. diameter:
S
Power Assisted Steering:
S
Front Tires :
235/80R 22.5G
Rear Tires:
235/80R 22.5G
Front and Rear Aluminum Wheels:
S
Steering Damper (Front):
O
Engine Equipment
Ford 7.3L Triton V8, 350 HP w/468 lb. Torque:
S
175 Amp Alternator:
S
TorqShift® 6-Speed Automatic w/Overdrive and Tow/Haul Mode:
S
Chassis Battery 78-amp:
S
12V Heavy Duty Chassis Batteries:
S
Sizes
Wheelbase:
228"
Exterior Length:
34'-6"
Exterior Width:
100"
Exterior Height:
12'10"
Interior Height:
82"
Interior Width:
96"
Interior Storage (cu.ft.):
–
Basement Storage (cu.ft.):
–
# of Slideouts:
2
Capacities
Fuel (gal):
80
Fresh Water (gal):
100
Gray Waste Water (gal):
50
Black Waste Water (gal):
50
Appliance Propane (gal) (WC):
25
Water Heater (Gas/Electric) (gal):
10
Construction
Aluminum Welded Interlocking Frames:
S
Dryseal Edge Coating for all Walls and Floors:
S
Vacu-Bond Aluminum Framed Constructed Roof and Sidewalls:
S
Premium Color Gel High Gloss Exterior Fiberglass Skin w/Matching Cap(s):
S
Quiet Ducted A/C System:
S
Pass Through Basement Storage:
S
Rotocast Molded Durable, Easy to Clean Sevice Compartment:
S
Steel Constructed Entry Step Box:
S
Electric Main/Bedroom/Wardrobe/Kitchen Slide Out Systems:
S
Powder Coated Steel Frame Chassis Construction:
S
Full Coverage Heavy Duty Undercoating:
S
CSA Build:
O
Exterior
Aerodynamic Fiberglass Cap w/Hood and Automotive Headlighting:
S
Rear Fiberglass Cap w/Automotive Lighting:
S
ABS Wheel Well Trims:
S
TPO Roof - Thermoplastic Polyolefin :
S
Legged Electric Patio Awning w/LED lighting:
S
Radiused Entry Door w/Screendoor, Latch, Deadbolt Lock:
S
Slide Out Awning Toppers Above All Slideouts:
S
Slam Latch Luggage Door Handles - Black:
S
Entry Grab Handle:
S
Power Entry Step w/Light:
S
Bottom/Side Swing Radiused, Color Matched Fiberglass Luggage Doors:
S
Single Pane Frameless Windows :
S
Dual Pane Frameless Windows :
O
Patio LED Light:
S
Front, Side and Rear Clearance and Marker lighting:
S
Gravity Fresh Water Fill:
S
Enclosed Exterior Waste Station w/Discharge Valves:
S
Trialer Hitch w/7-Way Round Tow Connection (8,000 lbs.):
S
TV Antenna - Unidirectional King Controls Jack Antenna:
S
LP Connection:
S
Four Point Fully Automatic Hydraulic Leveling Jacks:
S
Rear Ladder:
S
Partial Paint w/Vinyl Graphics:
S
Full-Body Paint:
O
Roof Vent Rain Covers:
O
Roof Mount Satellite Dish Prep:
S
KING Universal Satellite System:
O
Cab Exterior
Automotive One Piece Windshield:
S
Daytime Running Lights:
S
Driver/Passenger Slider Windows:
S
Fog Lamps:
S
Automotive Style Windshield Wiper System:
S
Remote Power/Heated Mirrors w/Turn Signals and Side Cameras - Chrome/Black:
S
Cab Interior
Driver Chair w/Reclining Back, Swivel and Manual Controls:
S
Driver Chair w/Reclining Back, Swivel and 6-way Power Controls:
O
Passenger Chair w/Reclining Back, Swivel and Manual Controls:
S
Driver/Passenger ABS Style Armrests:
S
Cup Holders - Driver/Passenger:
S
Power Windshield Roller Shade:
S
Manual Window Roller Shades - Driver/Passenger:
S
Overhead Map Lighting - Driver/Passenger:
S
Black Instrument Gauges w/Electronic Information Center:
S
High Output Dash Air Conditioning and Heat:
S
Electronic Cruise Control:
S
Windshield Wipers w/Delay:
S
Remote Switch for Power/Heated Mirrors:
S
Steering Wheel w/Tilt Column:
S
6" Color Monitor for Side and Rear Cameras:
S
Sony 9" Stereo w/AM/FM/Bluetooth/ MP3/USB - Phone Control - Android Auto & Apple Car Play w/Navigation - Siri Eyes Free - Built in HD Radio - Sirius/XM Ready (Requires Subscription) – Backup camera:
S
USB and Auxiliary Inputs:
S
Seat Belts - 3 Point Driver & Passenger w/Adjustable Straps:
S
12V Accessory Ports:
S
110-Volt AC Outlets :
S
Automotive Style Dash w/Dual Monitors and Work Station:
S
Generator On/Off Switch:
S
Engine Cover w/Snack Tray:
S
Auto Leveling Jack Controls:
S
Driver/Passenger Center Table:
S
Auxillary Start Switch:
S
Hide-A-Loft Drop Down Queen Bed:
S
Interior
Sofa - Jack-knife:
S
Sofa - Theatre Seating:
O
Facing Booth Dinette w/Dream Dinette Table and Single Door Storage:
S
Solid Surface Galley Top w/Sink Covers:
S
Surf-X Tops Throughout (Excluding Galley):
S
Feature Wall w/Accent Wall Covering:
S
Flat Ceiling w/Soft Touch Vinyl:
S
Vinyl Tile Flooring Throughout:
S
Non-Ozite Lined Cabinet Interiors w/Adjustable Shelving:
S
Full Extension Drawer Guides w/Latches:
S
Hidden Euro Hinges and Struts:
S
Cabinet Doors - Solid Wood, Raised Panel:
S
Galley Overhead Glass Inserts:
S
Slideout Fascia - Hardwood Interior Wood Color Coordinating :
S
Valances w/Lambrequins:
S
Manual Night Roller Shades:
S
Energy Efficient 3" LED Flush Mount Ceiling and Under Cabinet Reading Lights Throughout:
S
Chrome Faucets, Fixtures and Hardware:
S
Interior Entry
Battery Disconnect:
S
Interior Entry Grab Handle - Metal:
S
Entry Steps w/Pressed Tops:
S
Kitchen
Refrigerator - Residential Stainless Steel - Insignia:
S
Refer - LP 8 cu.ft. - Dometic:
O
Cooktop - 3-Burner:
S
Stainless Steel Over the Range Convection Microwave:
S
Tile Backsplash:
S
Sink - Stainless Steel, Single Bowl:
S
Sink - Stainless Steel, Double Bowl:
S
Sink - Stainless Steel Farmhouse-Style:
S
Residential Single Handle Faucet w/Pullout Sprayer :
S
Adjustable Shelves Throughout:
S
Power Ceiling Vent:
S
Bedroom or Bunk Area
King Bed:
S
Designer Bedspread, Headboard, Pillow Shams & Pillows:
S
C-PAP machine prep in bedroom overhead:
S
120V/USB Ports:
S
Reading Lights:
S
Lavy
Sink - Top-Mounted Stainless Steel:
S
Residential Faucet - Single Handle:
S
Medicine Cabinet w/Mirror:
S
ABS Shower Surround:
S
Glass Shower Door :
S
Shower Skylight:
S
Metal Shower Head w/Sliding Adjustable Bar, Soap Dish and Matching Single Valve Faucet:
S
Standard Toilet - Porcelain:
S
Macerator Toilet - Porcelain:
S
Power Ceiling Vent:
S
Entertainment
32″ Flat Screen LED TV (Bedroom):
S
39″ Flat Screen Smart LED TV (Living Area):
S
Living Area Ceiling Speakers:
S
Bluetooth Coach System in Bedroom w/Exterior Speakers:
S
Exterior Entertainment Center w/50" LED TV:
S
Electric & Utilities
A/C - Dual 13,500 BTU:
S
Furnace - 30,000 BTU:
S
50 Amp Service:
S
55 Amp Power Converter:
S
Inverter - Single 2000w:
S
WiFi Ranger Sky4:
S
Solar Panel - 100w:
S
Multiplex Wiring Control System w/4.3" touch screen panel:
S
6V Aux Batteries (4):
S
Generator - 5.5kW Onan Quiet:
S
Auto Gen Start:
S
Master Battery Disconnect Switch :
S
Water Pump - 12V 3GPM High Capacity Shurflo Water Pump:
S
Water Purification System:
S
Water Heater Bypass System:
S
City Water Hookup:
S
Exterior Shower :
S
Cable TV/Satellite Hookup:
S
Black Holding Tank Flush System - San-T-Flush:
S
Single Location Monitor panel w/LPG, Touch Sensor Tank Monitoring/Battery Readouts:
S
Fire Extinguisher, LP/CO and Smoke detectors:
S
GFCI Receptacle in Exterior Storage:
S
Washer/Dryer Prep - Combo:
S
Washer/Dryer - Combo:
O
Washer/Dryer - Stackable:
O
:
-
Chassis
Chassis Type:
Ford F-53 Motorhome Chassis
GVWR:
22000
GCWR:
26000
Rear Axle GAWR:
15000
Front Axle GAWR:
8000
Hitch Rating:
8000
Tongue Rating:
800
Front suspension: Tapered Multi-Leaf:
S
Rear suspension: Tapered Multi-Leaf:
S
Power - 4 Wheel Disc (Hydro-boost) w/ABS:
S
Shock Absorbers - Bilstein™ 1.63-in. diameter:
S
Power Assisted Steering:
S
Front Tires :
235/80R 22.5G
Rear Tires:
235/80R 22.5G
Front and Rear Aluminum Wheels:
S
Steering Damper (Front):
O
Engine Equipment
Ford 7.3L Triton V8, 350 HP w/468 lb. Torque:
S
175 Amp Alternator:
S
TorqShift® 6-Speed Automatic w/Overdrive and Tow/Haul Mode:
S
Chassis Battery 78-amp:
S
12V Heavy Duty Chassis Batteries:
S
Sizes
Wheelbase:
228"
Exterior Length:
35'-3"
Exterior Width:
100"
Exterior Height:
12'10"
Interior Height:
82"
Interior Width:
96"
Interior Storage (cu.ft.):
152
Basement Storage (cu.ft.):
145
# of Slideouts:
2
Capacities
Fuel (gal):
80
Fresh Water (gal):
100
Gray Waste Water (gal):
50
Black Waste Water (gal):
50
Appliance Propane (gal) (WC):
25
Water Heater (Gas/Electric) (gal):
10
Construction
Aluminum Welded Interlocking Frames:
S
Dryseal Edge Coating for all Walls and Floors:
S
Vacu-Bond Aluminum Framed Constructed Roof and Sidewalls:
S
Premium Color Gel High Gloss Exterior Fiberglass Skin w/Matching Cap(s):
S
Quiet Ducted A/C System:
S
Pass Through Basement Storage:
S
Rotocast Molded Durable, Easy to Clean Sevice Compartment:
S
Steel Constructed Entry Step Box:
S
Electric Main/Bedroom/Wardrobe/Kitchen Slide Out Systems:
S
Powder Coated Steel Frame Chassis Construction:
S
Full Coverage Heavy Duty Undercoating:
S
CSA Build:
O
Exterior
Aerodynamic Fiberglass Cap w/Hood and Automotive Headlighting:
S
Rear Fiberglass Cap w/Automotive Lighting:
S
ABS Wheel Well Trims:
S
TPO Roof - Thermoplastic Polyolefin :
S
Legged Electric Patio Awning w/LED lighting:
S
Radiused Entry Door w/Screendoor, Latch, Deadbolt Lock:
S
Slide Out Awning Toppers Above All Slideouts:
S
Slam Latch Luggage Door Handles - Black:
S
Entry Grab Handle:
S
Power Entry Step w/Light:
S
Bottom/Side Swing Radiused, Color Matched Fiberglass Luggage Doors:
S
Single Pane Frameless Windows :
S
Dual Pane Frameless Windows :
O
Patio LED Light:
S
Front, Side and Rear Clearance and Marker lighting:
S
Gravity Fresh Water Fill:
S
Enclosed Exterior Waste Station w/Discharge Valves:
S
Trialer Hitch w/7-Way Round Tow Connection (8,000 lbs.):
S
TV Antenna - Unidirectional King Controls Jack Antenna:
S
LP Connection:
S
Four Point Fully Automatic Hydraulic Leveling Jacks:
S
Rear Ladder:
S
Partial Paint w/Vinyl Graphics:
S
Full-Body Paint:
O
Roof Vent Rain Covers:
O
Roof Mount Satellite Dish Prep:
S
KING Universal Satellite System:
O
Cab Exterior
Automotive One Piece Windshield:
S
Daytime Running Lights:
S
Driver/Passenger Slider Windows:
S
Fog Lamps:
S
Automotive Style Windshield Wiper System:
S
Remote Power/Heated Mirrors w/Turn Signals and Side Cameras - Chrome/Black:
S
Cab Interior
Driver Chair w/Reclining Back, Swivel and Manual Controls:
S
Driver Chair w/Reclining Back, Swivel and 6-way Power Controls:
O
Passenger Chair w/Reclining Back, Swivel and Manual Controls:
S
Driver/Passenger ABS Style Armrests:
S
Cup Holders - Driver/Passenger:
S
Power Windshield Roller Shade:
S
Manual Window Roller Shades - Driver/Passenger:
S
Overhead Map Lighting - Driver/Passenger:
S
Black Instrument Gauges w/Electronic Information Center:
S
High Output Dash Air Conditioning and Heat:
S
Electronic Cruise Control:
S
Windshield Wipers w/Delay:
S
Remote Switch for Power/Heated Mirrors:
S
Steering Wheel w/Tilt Column:
S
6" Color Monitor for Side and Rear Cameras:
S
Sony 9" Stereo w/AM/FM/Bluetooth/ MP3/USB - Phone Control - Android Auto & Apple Car Play w/Navigation - Siri Eyes Free - Built in HD Radio - Sirius/XM Ready (Requires Subscription) – Backup camera:
S
USB and Auxiliary Inputs:
S
Seat Belts - 3 Point Driver & Passenger w/Adjustable Straps:
S
12V Accessory Ports:
S
110-Volt AC Outlets :
S
Automotive Style Dash w/Dual Monitors and Work Station:
S
Generator On/Off Switch:
S
Engine Cover w/Snack Tray:
S
Auto Leveling Jack Controls:
S
Driver/Passenger Center Table:
S
Auxillary Start Switch:
S
Hide-A-Loft Drop Down Queen Bed:
S
Interior
Sofa - Jack-knife:
S
Sofa - Theatre Seating:
O
Facing Booth Dinette w/Dream Dinette Table and Single Door Storage:
S
Solid Surface Galley Top w/Sink Covers:
S
Surf-X Tops Throughout (Excluding Galley):
S
Feature Wall w/Accent Wall Covering:
S
Flat Ceiling w/Soft Touch Vinyl:
S
Vinyl Tile Flooring Throughout:
S
Non-Ozite Lined Cabinet Interiors w/Adjustable Shelving:
S
Full Extension Drawer Guides w/Latches:
S
Hidden Euro Hinges and Struts:
S
Cabinet Doors - Solid Wood, Raised Panel:
S
Galley Overhead Glass Inserts:
S
Slideout Fascia - Hardwood Interior Wood Color Coordinating :
S
Valances w/Lambrequins:
S
Manual Night Roller Shades:
S
Energy Efficient 3" LED Flush Mount Ceiling and Under Cabinet Reading Lights Throughout:
S
Chrome Faucets, Fixtures and Hardware:
S
Interior Entry
Battery Disconnect:
S
Interior Entry Grab Handle - Metal:
S
Entry Steps w/Pressed Tops:
S
Kitchen
Refrigerator - Residential Stainless Steel - Insignia:
S
Refer - LP 8 cu.ft. - Dometic:
O
Cooktop - 3-Burner:
S
Stainless Steel Over the Range Convection Microwave:
S
Tile Backsplash:
S
Sink - Stainless Steel, Single Bowl:
S
Sink - Stainless Steel, Double Bowl:
S
Sink - Stainless Steel Farmhouse-Style:
S
Residential Single Handle Faucet w/Pullout Sprayer :
S
Adjustable Shelves Throughout:
S
Power Ceiling Vent:
S
Bedroom or Bunk Area
King Bed:
S
Designer Bedspread, Headboard, Pillow Shams & Pillows:
S
C-PAP machine prep in bedroom overhead:
S
120V/USB Ports:
S
Reading Lights:
S
Lavy
Sink - Top-Mounted Stainless Steel:
S
Residential Faucet - Single Handle:
S
Medicine Cabinet w/Mirror:
S
ABS Shower Surround:
S
Glass Shower Door :
S
Shower Skylight:
S
Metal Shower Head w/Sliding Adjustable Bar, Soap Dish and Matching Single Valve Faucet:
S
Standard Toilet - Porcelain:
S
Macerator Toilet - Porcelain:
S
Power Ceiling Vent:
S
Entertainment
32″ Flat Screen LED TV (Bedroom):
S
39″ Flat Screen Smart LED TV (Living Area):
S
Living Area Ceiling Speakers:
S
Bluetooth Coach System in Bedroom w/Exterior Speakers:
S
Exterior Entertainment Center w/50" LED TV:
S
Electric & Utilities
A/C - Dual 13,500 BTU:
S
Furnace - 30,000 BTU:
S
50 Amp Service:
S
55 Amp Power Converter:
S
Inverter - Single 2000w:
S
WiFi Ranger Sky4:
S
Solar Panel - 100w:
S
Multiplex Wiring Control System w/4.3" touch screen panel:
S
6V Aux Batteries (4):
S
Generator - 5.5kW Onan Quiet:
S
Auto Gen Start:
S
Master Battery Disconnect Switch :
S
Water Pump - 12V 3GPM High Capacity Shurflo Water Pump:
S
Water Purification System:
S
Water Heater Bypass System:
S
City Water Hookup:
S
Exterior Shower :
S
Cable TV/Satellite Hookup:
S
Black Holding Tank Flush System - San-T-Flush:
S
Single Location Monitor panel w/LPG, Touch Sensor Tank Monitoring/Battery Readouts:
S
Fire Extinguisher, LP/CO and Smoke detectors:
S
GFCI Receptacle in Exterior Storage:
S
Washer/Dryer Prep - Combo:
S
Washer/Dryer - Combo:
O
Washer/Dryer - Stackable:
O
:
-
Chassis
Chassis Type:
Ford F-53 Motorhome Chassis
GVWR:
22000
GCWR:
26000
Rear Axle GAWR:
15000
Front Axle GAWR:
8000
Hitch Rating:
8000
Tongue Rating:
800
Front suspension: Tapered Multi-Leaf:
S
Rear suspension: Tapered Multi-Leaf:
S
Power - 4 Wheel Disc (Hydro-boost) w/ABS:
S
Shock Absorbers - Bilstein™ 1.63-in. diameter:
S
Power Assisted Steering:
S
Front Tires :
235/80R 22.5G
Rear Tires:
235/80R 22.5G
Front and Rear Aluminum Wheels:
S
Steering Damper (Front):
O
Engine Equipment
Ford 7.3L Triton V8, 350 HP w/468 lb. Torque:
S
175 Amp Alternator:
S
TorqShift® 6-Speed Automatic w/Overdrive and Tow/Haul Mode:
S
Chassis Battery 78-amp:
S
12V Heavy Duty Chassis Batteries:
S
Sizes
Wheelbase:
242"
Exterior Length:
35'-9"
Exterior Width:
100"
Exterior Height:
12'10"
Interior Height:
82"
Interior Width:
96"
Interior Storage (cu.ft.):
128
Basement Storage (cu.ft.):
134
# of Slideouts:
2
Capacities
Fuel (gal):
80
Fresh Water (gal):
100
Gray Waste Water (gal):
50
Black Waste Water (gal):
50
Appliance Propane (gal) (WC):
25
Water Heater (Gas/Electric) (gal):
10
Construction
Aluminum Welded Interlocking Frames:
S
Dryseal Edge Coating for all Walls and Floors:
S
Vacu-Bond Aluminum Framed Constructed Roof and Sidewalls:
S
Premium Color Gel High Gloss Exterior Fiberglass Skin w/Matching Cap(s):
S
Quiet Ducted A/C System:
S
Pass Through Basement Storage:
S
Rotocast Molded Durable, Easy to Clean Sevice Compartment:
S
Heated Holding Tank Compartments:
S
Steel Constructed Entry Step Box:
S
Electric Main/Bedroom/Wardrobe/Kitchen Slide Out Systems:
S
Powder Coated Steel Frame Chassis Construction:
S
Full Coverage Heavy Duty Undercoating:
S
CSA Build:
O
Exterior
Aerodynamic Fiberglass Cap w/Hood and Automotive Headlighting:
S
Rear Fiberglass Cap w/Automotive Lighting:
S
ABS Wheel Well Trims:
S
TPO Roof - Thermoplastic Polyolefin :
S
Legged Electric Patio Awning w/LED lighting:
S
Radiused Entry Door w/Screendoor, Latch, Deadbolt Lock:
S
Slide Out Awning Toppers Above All Slideouts:
S
Slam Latch Luggage Door Handles - Black:
S
Entry Grab Handle:
S
Power Entry Step w/Light:
S
Bottom/Side Swing Radiused, Color Matched Fiberglass Luggage Doors:
S
Single Pane Frameless Windows :
S
Dual Pane Frameless Windows :
O
Patio LED Light:
S
Front, Side and Rear Clearance and Marker lighting:
S
Gravity Fresh Water Fill:
S
Enclosed Exterior Waste Station w/Discharge Valves:
S
Trialer Hitch w/7-Way Round Tow Connection (8,000 lbs.):
S
TV Antenna - Unidirectional King Controls Jack Antenna:
S
LP Connection:
S
Four Point Fully Automatic Hydraulic Leveling Jacks:
S
Rear Ladder:
S
Partial Paint w/Vinyl Graphics:
S
Full-Body Paint:
O
Roof Vent Rain Covers:
O
Roof Mount Satellite Dish Prep:
S
KING Universal Satellite System:
O
Cab Exterior
Automotive One Piece Windshield:
S
Daytime Running Lights:
S
Driver/Passenger Slider Windows:
S
Fog Lamps:
S
Automotive Style Windshield Wiper System:
S
Remote Power/Heated Mirrors w/Turn Signals and Side Cameras - Chrome/Black:
S
Cab Interior
Driver Chair w/Reclining Back, Swivel and Manual Controls:
S
Driver Chair w/Reclining Back, Swivel and 6-way Power Controls:
O
Passenger Chair w/Reclining Back, Swivel and Manual Controls:
S
Driver/Passenger ABS Style Armrests:
S
Cup Holders - Driver/Passenger:
S
Power Windshield Roller Shade:
S
Manual Window Roller Shades - Driver/Passenger:
S
Overhead Map Lighting - Driver/Passenger:
S
Black Instrument Gauges w/Electronic Information Center:
S
High Output Dash Air Conditioning and Heat:
S
Electronic Cruise Control:
S
Windshield Wipers w/Delay:
S
Remote Switch for Power/Heated Mirrors:
S
Steering Wheel w/Tilt Column:
S
6" Color Monitor for Side and Rear Cameras:
S
Sony 9" Stereo w/AM/FM/Bluetooth/ MP3/USB - Phone Control - Android Auto & Apple Car Play w/Navigation - Siri Eyes Free - Built in HD Radio - Sirius/XM Ready (Requires Subscription) – Backup camera:
S
USB and Auxiliary Inputs:
S
Seat Belts - 3 Point Driver & Passenger w/Adjustable Straps:
S
12V Accessory Ports:
S
110-Volt AC Outlets :
S
Automotive Style Dash w/Dual Monitors and Work Station:
S
Generator On/Off Switch:
S
Engine Cover w/Snack Tray:
S
Auto Leveling Jack Controls:
S
Driver/Passenger Center Table:
S
Auxillary Start Switch:
S
Hide-A-Loft Drop Down Queen Bed:
S
Interior
Sofa - Jack-knife:
S
Sofa - Theatre Seating:
O
Facing Booth Dinette w/Dream Dinette Table and Single Door Storage:
S
Solid Surface Galley Top w/Sink Covers:
S
Surf-X Tops Throughout (Excluding Galley):
S
Electric Fireplace:
S
Feature Wall w/Accent Wall Covering:
S
Feature Wall w/Surf-X Covering:
S
Flat Ceiling w/Soft Touch Vinyl:
S
Vinyl Tile Flooring Throughout:
S
Non-Ozite Lined Cabinet Interiors w/Adjustable Shelving:
S
Full Extension Drawer Guides w/Latches:
S
Hidden Euro Hinges and Struts:
S
Cabinet Doors - Solid Wood, Raised Panel:
S
Galley Overhead Glass Inserts:
S
Slideout Fascia - Hardwood Interior Wood Color Coordinating :
S
Valances w/Lambrequins:
S
Manual Night Roller Shades:
S
Energy Efficient 3" LED Flush Mount Ceiling and Under Cabinet Reading Lights Throughout:
S
Chrome Faucets, Fixtures and Hardware:
S
Interior Entry
Battery Disconnect:
S
Interior Entry Grab Handle - Metal:
S
Entry Steps w/Pressed Tops:
S
Kitchen
Refrigerator - Residential Stainless Steel - Insignia:
S
Refer - LP 8 cu.ft. - Dometic:
O
Cooktop - 3-Burner:
S
Stainless Steel Over the Range Convection Microwave:
S
Tile Backsplash:
S
Sink - Stainless Steel, Single Bowl:
S
Sink - Stainless Steel, Double Bowl:
S
Sink - Stainless Steel Farmhouse-Style:
S
Residential Single Handle Faucet w/Pullout Sprayer :
S
Adjustable Shelves Throughout:
S
Power Ceiling Vent:
S
Bedroom or Bunk Area
King Bed:
S
Designer Bedspread, Headboard, Pillow Shams & Pillows:
S
C-PAP machine prep in bedroom overhead:
S
120V/USB Ports:
S
Reading Lights:
S
Lavy
Sink - Top-Mounted Stainless Steel:
S
Residential Faucet - Single Handle:
S
Medicine Cabinet w/Mirror:
S
ABS Shower Surround:
S
Glass Shower Door :
S
Shower Skylight:
S
Metal Shower Head w/Sliding Adjustable Bar, Soap Dish and Matching Single Valve Faucet:
S
Standard Toilet - Porcelain:
S
Power Ceiling Vent:
S
Entertainment
32″ Flat Screen LED TV (Bedroom):
S
39″ Flat Screen Smart LED TV (Living Area):
S
Living Area Ceiling Speakers:
S
Bluetooth Coach System in Bedroom w/Exterior Speakers:
S
Exterior Entertainment Center w/50" LED TV:
S
Electric & Utilities
A/C - Dual 13,500 BTU:
S
Furnace - 34,000 BTU:
S
50 Amp Service:
S
55 Amp Power Converter:
S
Inverter - Single 2000w:
S
WiFi Ranger Sky4:
S
Solar Panel - 100w:
S
Multiplex Wiring Control System w/4.3" touch screen panel:
S
6V Aux Batteries (4):
S
Generator - 5.5kW Onan Quiet:
S
Auto Gen Start:
S
Master Battery Disconnect Switch :
S
Water Pump - 12V 3GPM High Capacity Shurflo Water Pump:
S
Water Purification System:
S
Water Heater Bypass System:
S
City Water Hookup:
S
Exterior Shower :
S
Cable TV/Satellite Hookup:
S
Black Holding Tank Flush System - San-T-Flush:
S
Single Location Monitor panel w/LPG, Touch Sensor Tank Monitoring/Battery Readouts:
S
Fire Extinguisher, LP/CO and Smoke detectors:
S
GFCI Receptacle in Exterior Storage:
S
Washer/Dryer Prep - Combo:
S
Washer/Dryer - Combo:
O
Washer/Dryer - Stackable:
O
:
-
Chassis
Chassis Type:
Ford F-53 Motorhome Chassis
GVWR:
26000
GCWR:
30000
Rear Axle GAWR:
17500
Front Axle GAWR:
9000
Hitch Rating:
8000
Tongue Rating:
800
Front suspension: Tapered Multi-Leaf:
S
Rear suspension: Tapered Multi-Leaf:
S
Power - 4 Wheel Disc (Hydro-boost) w/ABS:
S
Shock Absorbers - Bilstein™ 1.63-in. diameter:
S
Power Assisted Steering:
S
Front Tires :
255/80R 22.5G
Rear Tires:
255/80R 22.5G
Front and Rear Aluminum Wheels:
S
Steering Damper (Front):
O
Engine Equipment
Ford 7.3L Triton V8, 350 HP w/468 lb. Torque:
S
175 Amp Alternator:
S
TorqShift® 6-Speed Automatic w/Overdrive and Tow/Haul Mode:
S
Chassis Battery 78-amp:
S
12V Heavy Duty Chassis Batteries:
S
Sizes
Wheelbase:
252"
Exterior Length:
38'-11"
Exterior Width:
100"
Exterior Height:
12'10"
Interior Height:
82"
Interior Width:
96"
Interior Storage (cu.ft.):
–
Basement Storage (cu.ft.):
–
# of Slideouts:
3
Capacities
Fuel (gal):
80
Fresh Water (gal):
100
Gray Waste Water (gal):
80
Black Waste Water (gal):
50
Appliance Propane (gal) (WC):
25
Tankless Water Heater:
S
Construction
Aluminum Welded Interlocking Frames:
S
Dryseal Edge Coating for all Walls and Floors:
S
Vacu-Bond Aluminum Framed Constructed Roof and Sidewalls:
S
Premium Color Gel High Gloss Exterior Fiberglass Skin w/Matching Cap(s):
S
Quiet Ducted A/C System:
S
Pass Through Basement Storage:
S
Rotocast Molded Durable, Easy to Clean Sevice Compartment:
S
Heated Holding Tank Compartments:
S
Steel Constructed Entry Step Box:
S
Electric Main/Bedroom/Wardrobe/Kitchen Slide Out Systems:
S
Powder Coated Steel Frame Chassis Construction:
S
Full Coverage Heavy Duty Undercoating:
S
CSA Build:
O
Exterior
Aerodynamic Fiberglass Cap w/Hood and Automotive Headlighting:
S
Rear Fiberglass Cap w/Automotive Lighting:
S
ABS Wheel Well Trims:
S
TPO Roof - Thermoplastic Polyolefin :
S
Legged Electric Patio Awning w/LED lighting:
S
Radiused Entry Door w/Screendoor, Latch, Deadbolt Lock:
S
Slide Out Awning Toppers Above All Slideouts:
S
Slam Latch Luggage Door Handles - Black:
S
Entry Grab Handle:
S
Power Entry Step w/Light:
S
Bottom/Side Swing Radiused, Color Matched Fiberglass Luggage Doors:
S
Single Pane Frameless Windows :
S
Dual Pane Frameless Windows :
O
Patio LED Light:
S
Front, Side and Rear Clearance and Marker lighting:
S
Gravity Fresh Water Fill:
S
Enclosed Exterior Waste Station w/Discharge Valves:
S
Trialer Hitch w/7-Way Round Tow Connection (8,000 lbs.):
S
TV Antenna - Unidirectional King Controls Jack Antenna:
S
LP Connection:
S
Four Point Fully Automatic Hydraulic Leveling Jacks:
S
Rear Ladder:
S
Partial Paint w/Vinyl Graphics:
S
Full-Body Paint:
O
Roof Vent Rain Covers:
O
Roof Mount Satellite Dish Prep:
S
KING Universal Satellite System:
O
Cab Exterior
Automotive One Piece Windshield:
S
Daytime Running Lights:
S
Driver/Passenger Slider Windows:
S
Fog Lamps:
S
Automotive Style Windshield Wiper System:
S
Remote Power/Heated Mirrors w/Turn Signals and Side Cameras - Chrome/Black:
S
Cab Interior
Driver Chair w/Reclining Back, Swivel and Manual Controls:
S
Driver Chair w/Reclining Back, Swivel and 6-way Power Controls:
O
Passenger Chair w/Reclining Back, Swivel and Manual Controls:
S
Driver/Passenger ABS Style Armrests:
S
Cup Holders - Driver/Passenger:
S
Power Windshield Roller Shade:
S
Manual Window Roller Shades - Driver/Passenger:
S
Overhead Map Lighting - Driver/Passenger:
S
Black Instrument Gauges w/Electronic Information Center:
S
High Output Dash Air Conditioning and Heat:
S
Electronic Cruise Control:
S
Windshield Wipers w/Delay:
S
Remote Switch for Power/Heated Mirrors:
S
Steering Wheel w/Tilt Column:
S
6" Color Monitor for Side and Rear Cameras:
S
Sony 9" Stereo w/AM/FM/Bluetooth/ MP3/USB - Phone Control - Android Auto & Apple Car Play w/Navigation - Siri Eyes Free - Built in HD Radio - Sirius/XM Ready (Requires Subscription) – Backup camera:
S
USB and Auxiliary Inputs:
S
Seat Belts - 3 Point Driver & Passenger w/Adjustable Straps:
S
12V Accessory Ports:
S
110-Volt AC Outlets :
S
Automotive Style Dash w/Dual Monitors and Work Station:
S
Generator On/Off Switch:
S
Engine Cover w/Snack Tray:
S
Auto Leveling Jack Controls:
S
Driver/Passenger Center Table:
S
Auxillary Start Switch:
S
Hide-A-Loft Drop Down Queen Bed:
S
Interior
Sofa - Jack-knife:
S
Sofa - Theatre Seating:
O
Facing Booth Dinette w/Dream Dinette Table and Single Door Storage:
S
Solid Surface Galley Top w/Sink Covers:
S
Surf-X Tops Throughout (Excluding Galley):
S
Feature Wall w/Accent Wall Covering:
S
Flat Ceiling w/Soft Touch Vinyl:
S
Vinyl Tile Flooring Throughout:
S
Non-Ozite Lined Cabinet Interiors w/Adjustable Shelving:
S
Full Extension Drawer Guides w/Latches:
S
Hidden Euro Hinges and Struts:
S
Cabinet Doors - Solid Wood, Raised Panel:
S
Galley Overhead Glass Inserts:
S
Slideout Fascia - Hardwood Interior Wood Color Coordinating :
S
Valances w/Lambrequins:
S
Manual Night Roller Shades:
S
Energy Efficient 3" LED Flush Mount Ceiling and Under Cabinet Reading Lights Throughout:
S
Chrome Faucets, Fixtures and Hardware:
S
Interior Décor Choices:
3
Wood Color Choices:
4
Interior Entry
Battery Disconnect:
S
Interior Entry Grab Handle - Metal:
S
Entry Steps w/Pressed Tops:
S
Kitchen
Refrigerator - Residential Stainless Steel - Insignia:
S
Refer - LP 8 cu.ft. - Dometic:
O
Cooktop - 3-Burner:
S
Stainless Steel Over the Range Convection Microwave:
S
Tile Backsplash:
S
Sink - Stainless Steel, Single Bowl:
S
Sink - Stainless Steel, Double Bowl:
S
Sink - Stainless Steel Farmhouse-Style:
S
Residential Single Handle Faucet w/Pullout Sprayer :
S
Adjustable Shelves Throughout:
S
Power Ceiling Vent:
S
Bedroom or Bunk Area
King Bed:
S
Designer Bedspread, Headboard, Pillow Shams & Pillows:
S
C-PAP machine prep in bedroom overhead:
S
120V/USB Ports:
S
Reading Lights:
S
Lavy
Sink - Top-Mounted Stainless Steel:
S
Residential Faucet - Single Handle:
S
Medicine Cabinet w/Mirror:
S
ABS Shower Surround:
S
Glass Shower Door :
S
Shower Skylight:
S
Metal Shower Head w/Sliding Adjustable Bar, Soap Dish and Matching Single Valve Faucet:
S
Standard Toilet - Porcelain:
S
Macerator Toilet - Porcelain:
S
Power Ceiling Vent:
S
Entertainment
32″ Flat Screen LED TV (Bedroom):
S
39″ Flat Screen Smart LED TV (Living Area):
S
Living Area Ceiling Speakers:
S
Bluetooth Coach System in Bedroom w/Exterior Speakers:
S
Exterior Entertainment Center w/50" LED TV:
S
Electric & Utilities
A/C - Dual 13,500 BTU:
S
Furnace - 20,000 BTU (Rear):
S
Furnace - 30,000 BTU (Front):
S
50 Amp Service:
S
55 Amp Power Converter:
S
Inverter - Single 2000w:
S
WiFi Ranger Sky4:
S
Solar Panel - 100w:
S
Multiplex Wiring Control System w/4.3" touch screen panel:
S
6V Aux Batteries (4):
S
Generator - 5.5kW Onan Quiet:
S
Auto Gen Start:
S
Master Battery Disconnect Switch :
S
Water Pump - 12V 5.3GPM High Capacity AquaJet Water Pump:
S
Water Purification System:
S
Water Heater Bypass System:
S
City Water Hookup:
S
Exterior Shower :
S
Cable TV/Satellite Hookup:
S
Black Holding Tank Flush System - San-T-Flush:
S
Single Location Monitor panel w/LPG, Touch Sensor Tank Monitoring/Battery Readouts:
S
Fire Extinguisher, LP/CO and Smoke detectors:
S
GFCI Receptacle in Exterior Storage:
S
Washer/Dryer Prep - Combo:
S
Washer/Dryer - Combo:
O
Washer/Dryer - Stackable:
O
:
